In petroleum engineering cementing experiments, thickening time is one of the important parameters for evaluating the performance of cement slurry, which is directly related to the operable time of construction and wellbore safety. The NITHONS atmospheric pressure thickening instrument is specially designed to determine the thickening characteristics of cement slurry under atmospheric pressure, and it is an indispensable key device in laboratory research and quality control.

🔧 Product Purpose | Application
The atmospheric pressure thickening instrument is mainly used to determine the thickening behavior of cement slurry with time under stirring conditions, helping users understand the working time window (i.e., initial and final thickening time) of cement slurry in actual construction. It is suitable for:

Optimization of cement slurry formulations

Screening and evaluation of additives

Adjustment of process parameters

Daily quality monitoring

🛠 Equipment Composition | System Components

Main machine stirring system: Equipped with a high-strength motor and precision stirring blades to simulate the circulating stirring state of cement slurry in the wellbore.

Constant temperature control unit: Adopts an intelligent heating module to regulate the water bath temperature and ensure stable experimental temperature (generally within 80°C).

Touch operation panel (optional): Humanized interface for setting stirring speed, test duration, and alarm parameters.

🌟 Product Advantages | Key Advantages

Precise data: Real-time recording of torque changes to accurately determine initial and final thickening times.

Easy to operate: One-key start program, automatic control of stirring, heating, and data acquisition.

High cost-performance: Compared with high-pressure thickening instruments, it has a simple structure and is suitable for most experimental scenarios.

Convenient maintenance: Modular design for easy daily cleaning and maintenance.

Customization support: Can provide customized services such as special rotation speeds, data interfaces, and touch screens according to customer needs.

📌 Typical Application Scenarios | Typical Use Cases

Cement slurry design and verification in cementing laboratories

Product research and development and performance evaluation in cement additive enterprises

Wellsite simulation and process optimization experiments in petroleum service companies

Teaching and research in universities and research institutions

Technical Parameters

Max. Temperature	93℃	Max. Working Pressure	Atmospheric
Input Voltage	AC 100-110V 60Hz/220V 50Hz	Heater Power	1200W*2
Consistency Range	0-100Bc	Rotation Speed	150±15rpm
Dimensions (WDH)	546565cm	Weight	75kg
Pressure of Cooling Water	0.2-0.5MPa	Connector Size of Cooling Water Pipe	Inner Diameter:10mm
Input Power	2600W	Connector Size of Cooling Water Pipe Slurry Cup Volume	Inner Diameter: 10mm
Input Power	2600W	Connector Size of Cooling Water Pipe Slurry Cup Volume	470ml

Exhibition

For over ten years, the NITHONS Atmospheric Consistometer has remained in continuous operation without major issues, a testament to its remarkable reliability and consistent performance. Throughout this extended period, it has been a steadfast tool, ensuring seamless testing processes for our clients.

Moreover, Nithons' online after - sales support stands out for its exceptional efficiency. Regardless of when technical glitches or inquiries occur, their team promptly engages, offering timely solutions to address any concerns.

The NITHONS Atmospheric Consistometer has operated smoothly for over a decade, demonstrating unparalleled stability. Unlike top - tier foreign brands, it offers significantly lower routine maintenance costs, reducing long - term expenses. Compared with domestic models, it surpasses them in quality, ensuring higher durability and precision. Additionally, Nithons provides prompt online after - sales service. Whenever issues arise, their team responds swiftly, making it a reliable choice both in terms of cost - effectiveness and performance.
